EVALUA
19-5010; Rev 1; 3/10
TION KIT
AVA ILABLE
5GHz Receiver
General Description
The MAX2852 is a single-chip RF receiver IC designed
for 5GHz wireless HDMI applications. The IC includes
all circuitry required to implement the complete receiver
function and crystal oscillator, providing a fully integrated
transmit path, VCO, frequency synthesis, and baseband/
control interface. It includes a fast-settling, sigma-delta
RF fractional synthesizer with 76Hz frequency program-
ming step size. The IC also integrates on-chip I/Q ampli-
tude and phase-error calibration circuits.
The receiver includes both an in-channel RSSI and an
RF RSSI.
The receiver chip is housed in a small, 68-pin thin QFN
leadless plastic package with exposed pad.
Applications
5GHz Wireless HDMI K (WHDI)
5GHz FDD Backhaul and WiMAX K
Features
S 5GHz Single IEEE 802.11a Receiver
4900MHz to 5900MHz Frequency Range
4.5dB Rx Noise Figure
70dB Rx Gain-Control Range with 2dB Step
Size, Digitally Controlled
60dB Dynamic Range Receiver RSSI
RF Wideband Receiver RSSI
Programmable 20MHz/40MHz Rx I/Q Lowpass
Channel Filters
Sigma-Delta Fractional-N PLL with 76Hz
Resolution
Monolithic Low-Noise VCO with -35dBc
Integrated Phase Noise
4-Wire SPI? Digital Interface
I/Q Analog Baseband Interface
On-Chip Digital Temperature Sensor Readout
Complete Baseband Interface
S +2.7V to +3.6V Supply Voltage
S Small, 68-Pin Thin QFN Package (10mm x 10mm)
Ordering Information
PART
MAX2852ITK+
TEMP RANGE
-25 N C to +85 N C
PIN-PACKAGE
68 Thin QFN-EP*
* EP = Exposed pad.
+ Denotes a lead(Pb)-free/RoHS-compliant package.
SPI is a trademark of Motorola, Inc.
HDMI is a trademark of HDMI Licensing, LLC.
Typical Operating Circuit appears at end of data sheet.
WiMAX is a trademark of WiMAX Forum.
_______________________________________________________________ Maxim Integrated Products 1
For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.
